Stationary jaw crushers

Sandvik jaw crushers are reliable, high-performing crushers built to optimize primary crushing applications in mines and quarries.

These tough crushers are delivered with everything you need for plug-and-play installation and safety features to keep operators out of danger. Backed up with a complete Reliability and Protection package, they get you up-and-running fast. And keep your operations running for a long time to come.

Five reasons for choosing Sandvik jaw crushers

Complete jaw crushing solution

Sandvik Jaw crushers come with everything you need for plug-and-play primary crushing operations. Each jaw crusher comes with feed hopper, feed hopper interface, drive and subframe with v-belt guard and motor bracket, our unique guarding retraction arrangement and toggle plate stop. The wide range of jaw plates can be mixed and reversed to ensure optimal, versatile crushing.

Easy to set up and install

When you order from Sandvik you order from a global supplier with equipment, parts and service close to your operations. Choose a complete crusher solution, or adapt according to your needs, and we make sure you’re up and running in the shortest possible time – driving up profits while driving down costs.

Smart, sustainable working

Sustainability is about doing what we can to protect the planet. That’s why all Sandvik jaw crushers are built for the circular economy. You can recycle the complete machine – all the metal, and even the rubber seals. The main motor is IE3 approved to give you the best combination of energy efficiency, reduced operational costs and carbon footprint.

Putting safety first

Your safety is our number one priority. Which is why Sandvik uses the highest quality materials and parts in our equipment. Our Jaw crushers include lifting tools for safe maintenance and a unique guarding retraction to keep people safe during operation. We can provide a modular service platform to ensure safe maintenance when working in the crushing chamber.

Reliable crushing

When you buy Sandvik Original Equipment and parts you know you are buying quality that’s built to last – in the tough conditions they are built for. Backed up by a Sandvik Reliability and Protection package you are assured of trouble-free ownership through extended warranty coverage, periodic inspections, on-site troubleshooting and trend analysis. A product range with a uniform plug-and-play solution that ensures easy and safe service and guaranteed productivity through reliability and availability.

Advantages

  • Safe and easy operation and maintenance
  • Proven technology with welded design offer a reliable operation
  • High capacity
  • High reduction
  • Deep symmetrical crushing chamber and optimized nip angle maximizes size reduction and production capacity
  • Wider intake opening offers possibility to handle larger feed
  • Solid split free bearing housing
  • Welded frame with high rigidity/weight ratio
  • Guarding for retraction arrangement


Jaw plates for all types of feed

Sandvik offers seven teeth patterns and up to three alloy selections (M1, M2, M8) to suit the different types of quarrying and mining applications. Our patterns include Wide Teeth (WT), Wide Wave (WW), Corrugated (C), Coarse Corrugated (CC), Sharp Teeth (ST), Heavy Duty (HD), Heavy Duty Ultra-Thick (UT).

M1 is the standard alloy, offering high resistance to shock and impact. It also work well with hard rock. Our M2 and M8 alloys offer high resistance to abrasive rock, but have lower resistance to shock and impact.

The optimal jaw plate selection can be determined based on the rock/ore type characteristics (WI, AI) and the feed characteristics (friction, gradation).

Wide teeth (WT)

For feed with a lot of fines; good wear resistance; can be used on both fixed and moving sides.

Shartp teeth (ST)

For flaky feed material with a lot of fines; good gripping ability; very good top-size control. Highly recommended if the AI is not too high.

Corrugated (C)

Suitable for less abrasive material; good for small CSS settings; good top-size control

Coarse corrugated (CC)

For abrasive material and feed with a lot of fines; used for large CSS settings; good top-size control.

Heavy duty (HD)

For very abrasive material; less top-size control. Can be combined with a CC moving plate.

HD ultra thick (UT)

For very abrasive material; less top-size control. Based on HD pattern with extra 30 mm thickness for longer wear life.

To be used with the CC moving plate

  • Reliability and protection package

    Unpredictability is the enemy of productivity. The Sandvik Reliability and Protection package is designed to keep you in control of your costs and efficiency at all times. It includes on-site periodic inspections that enable proactive preventative maintenance recommendations, trend analysis, and our exclusive 1 + 2 years equipment warranty – protecting your investment and giving you an improved cost of ownership.

  • Sandvik Crushology knowledge portal

    The knowledge hub

    Over the last 150 years, we've learned a thing or two about crushing and screening. As innovators and experts in the field, we have a deep understanding of technical and mechanical factors, but there’s more to it than that. Find out at our knowledge hub for crushing and screening.
