Hybrid tracked offering
QE442e Free Flow scalper
- Equipment
- Sandvik heavy duty 2 deck free flow screen
- Screen size
- 5.4 x 1.75 m (18 x 6 ft)
- Capacity
- Up to 400 mtph (441 stph)
Sandvik QE442e free flow provides you with a versatile and highly efficient mobile solution for difficult to screen materials. The 'e' variant is fitted with the hybrid drive for lower operating costs and reduced carbon footprint.
-
Hybrid 'e' drive
with electric plug-in to run in diesel or electric mode for lower operating costs
-
Aggressive free flow screen
with wide range of adjustable throws and speeds enables the bottom deck to be tailored for numerous applications
-
Easy operation
through a unique colour-coded control panel with sequential start / stop
-
Operator safety ensured
with 2 speed radio tracking and feeder control as standard
-
Massive stockpiling capability
through integrated hydraulic conveyors
Product data
- Equipment
- Sandvik heavy duty 2 deck free flow screen
- Screen size
- 5.4 x 1.75 m (18 x 6 ft)
- Capacity
- Up to 400 mtph (441 stph)
- Engine
- C4.4 110 kW (147 hp)*
- Transport length
- 16.3 m (53.7 ft)
- Transport width
- 3.2 m (10.6 ft)
- Transport height
- 3.5 m (11.6 ft)
- Weight
- 38,267 kg (84,364 lb)
* Please refer to technical specification sheet for alternative engine options.
Please note all weights and dimensions are for standard units only.
Additional product information
-
QE442e Free Flow
Sandvik QE442e Free Flow features a heavy-duty scalping screen which allows you to process large un-screened material on the rigid scalping top deck, whilst providing a fine screening solution on the dual motion lower deck. The Free Flow screen itself is hugely versatile, with a wide range of settings designed to suit your specific needs.
It is your ideal solution for processing materials such as soils, aggregates, ores, waste, biomass and other products with high moisture contents, whilst maintaining superior levels of productivity.
Designed and built for durability Sandvik QE442e Free Flow incorporates the same class leading features as our Sandvik QE442e. Prioritizing operator safety, it is fitted with feeder control and 2 speed radio tracking fitted as standard.
Other models within this range include Sandvik QE342e and QE442e.
-
Lower your operating cost and carbon footprint
In our drive towards a more sustainable future and helping our customers to lower their operating costs, we have developed a hybrid drive option for our Q-Range of screens and scalpers. This electric plug-in solution allows you to choose between operating in electric-hydraulic or diesel-hydraulic mode, giving you the flexibility to select the energy source which best suits your requirements. This will enable you to lower your operating cost as well as your carbon footprint.
Available on Sandvik QA442 and QA452 models within our screening range and QE342, QE442 and QE442 Free Flow in our scalper offering.
